Fully Automatic Hybrid - Carbon and Sand Filter With Water Softener [Hybrid I-75] 4000 LPH
(0) Reviews
153500.00250000.00
The Purity Hub Hybrid I-75 is a fully automatic, high-performance hybrid filtration system that combines carbon and sand filtration with a water softener to deliver complete and efficient water purification. Unlike Purity Hub Hybrid Single Valve Models, the Hybrid I-75 is designed with two dedicated multiport valves—one for the Carbon & Sand Filter and the other exclusively for the Softener. This intelligent separation is essential because carbon and sand media require frequent backwashing, especially in high-turbidity water conditions, whereas the softener’s resin regeneration is based on Output-Based Regeneration (OBR). By keeping the softener cycle isolated, the system ensures accurate resin regeneration while allowing independent and timely backwashing of the filters.
Both multiport valves are crafted with hard-sealing ceramic discs, fired at extreme temperatures between 1680°C to 2200°C, offering unmatched durability, corrosion resistance, and near-zero maintenance. Additionally, the two valves are smartly interlocked—each valve checks the operational status of the other before initiating its cleaning cycle. This intelligent interlocking system ensures that the Carbon & Sand Filter backwash or Resin Regeneration only begins when adequate water is available, preventing pressure drops and enhancing overall system efficiency.
The system comes preloaded with premium-grade sand and carbon media, along with 15% cross-linked ion exchange resin, ensuring superior filtration and softening performance. Engineered for Indian weather conditions, it includes weather-resistant wiring, tool-free push-fit brine pipe connections, Purity Hub’s patented Low Salt Alarm, a Smart Info Panel, LP-BFT (Low Pressure – Before Tank) technology, and a dual-function regeneration and pressure pump—making the Hybrid I-75 a powerful, eco-efficient, and smart water treatment solution built for long-term reliability.
Free Shipping | Expert Installation Service | 3 Years Warranty
Purity Hub Hybrid I-75 — Product Features
1. Advanced Dual Multiport Valve System with Intelligent Interlocking
The Hybrid I-75 features two dedicated multiport valves to independently manage the Carbon & Sand Filter and the Water Softener. This dual system is specifically designed to handle high turbidity levels in water, allowing frequent backwashing of the Carbon and Sand filters without affecting the softener cycle. Both MPVs are engineered with high-durability ceramic moving and fixed discs and can operate under pressure with minimal maintenance. The integrated Purity Hub Interlocking System ensures that only one unit undergoes backwashing or regeneration at a time—each valve checks the status of the other before initiating its cleaning cycle, guaranteeing optimal water availability.
Hybrid I-75 दो अलग-अलग मल्टीपोर्ट वाल्व के माध्यम से कार्बन और सैंड फिल्टर तथा वॉटर सॉफ्टनर को अलग-अलग संचालित करता है। जहां पानी में गंदगी अधिक हो, वहां कार्बन और सैंड फिल्टर को बार-बार साफ करने की आवश्यकता होती है, लेकिन सॉफ्टनर को नहीं। यह तकनीक विशेष सिरेमिक डिस्क से युक्त है और प्रेशर पर सीधा कार्य करने में सक्षम है। प्योरिटी हब का इंटरलॉकिंग सिस्टम यह सुनिश्चित करता है कि जब एक यूनिट क्लीनिंग मोड में हो, तो दूसरा यूनिट तब तक शुरू न हो जब तक पहला पूरा न हो जाए – जिससे पानी की उपलब्धता सुनिश्चित होती है।2. Integrated Equipment for Cost & Maintenance Efficiency
Both MPVs (for filter and softener) share core components like vacuum breakers, pressure gauges, electronic ball valves, and a single regeneration/backwash motor. This unified system significantly reduces installation costs and long-term maintenance needs.
दोनों मल्टीपोर्ट्स – फ़िल्टर और सॉफ्टनर – एक ही सिस्टम के तहत समान उपकरणों का उपयोग करते हैं, जिससे लागत और मेंटिनेंस दोनों में बचत होती है।3. Complete Water Workstation
Effectively removes dust, mud, odor, and water hardness. This all-in-one unit can be upgraded anytime, making it a future-ready water treatment solution.
Hybrid I-75 मिट्टी, बदबू और हार्डनेस को पूरी तरह हटाता है – यह एक कम्पलीट वॉटर वर्कस्टेशन की तरह काम करता है जिसे ज़रूरत के अनुसार अपग्रेड किया जा सकता है।4. Time & Volume-Based Backwash and Regeneration
Customizable cleaning cycles based on water usage or preset time intervals, providing adaptability across different use cases.
यह यूनिट तय समय या पानी की खपत के आधार पर अपने आप सफाई प्रक्रिया (रीजनरेशन) शुरू कर सकता है।5. High Flow Rate – 4000 Litres/Hour
Supports up to 4000 LPH, easily compatible with standard 1-inch plumbing lines.
4000 लीटर प्रति घंटा का हाई फ्लो रेट — जिसे आसानी से 1 इंच की प्लम्बिंग लाइन में इंस्टॉल किया जा सकता है।6. Inbuilt Patented Low Salt Alarm System
Our proprietary sensor technology alerts users automatically when brine salt is low, ensuring uninterrupted softening and timely salt refills.
ब्राइन टैंक में नमक कम होने पर यह सिस्टम अलार्म के ज़रिए खुद सूचना देता है, जिससे बिना नमक के सॉफ्टनर चलने की परेशानी नहीं होती।7. All-Weather Protection
All key components including MPVs, motors, and adaptors are enclosed in protective plastic & metal covers, ensuring long life in heat, rain, or dust.
हर जरूरी पार्ट — जैसे मल्टीपोर्ट वाल्व, मोटर व एडॉप्टर — को सुरक्षा कवच से ढका गया है ताकि धूप, बारिश और धूल से बचाव हो सके।8. Salt Regeneration Safety with LP-BFT (Low Pressure Before Tank)
This intelligent feature prevents regeneration if water pressure is insufficient, resuming automatically when water is available — ensuring only soft water enters your tank.
एलपी–बीएफटी तकनीक यह सुनिश्चित करती है कि सफाई प्रक्रिया तब तक न हो जब तक पर्याप्त पानी न हो, जिससे टैंक में हमेशा साफ और सॉफ्ट पानी ही जाए।9. 100-Litre Large Brine Tank (Expandable)
Includes a spacious brine tank to store more salt for longer periods. Custom size upgrades available on request.
100 लीटर का बड़ा ब्राइन टैंक अधिक नमक स्टोर करने की सुविधा देता है। ज़रूरत पर बड़ा टैंक भी उपलब्ध कराया जा सकता है।10. Integrated MPV-Driven Regeneration Motor
Comes with an inbuilt motor to automate the regeneration process—no need to manually operate borewell or sump motors.
रीजनरेशन मोटर सिस्टम के अंदर पहले से लगी होती है, जिससे कोई मैन्युअल हस्तक्षेप नहीं करना पड़ता।11. Smart Cleaning Circuit by Purity Hub
If the regeneration motor doesn’t receive water, the Smart Circuit will automatically switch on the sump/bore motor—ensuring never a dry regeneration cycle.
अगर रिजनरेशन के समय पानी नहीं मिल रहा है, तो स्मार्ट सर्किट ऑटोमेटिक बोर/संप मोटर चालू कर देता है – जिससे हमेशा सही सफाई होती है।12. Smart Ball-Valve Integration for Dual Usage
Offers flexibility to use the regeneration motor as a pressure pump or to use your existing high-pressure pump as the regeneration motor — a first-in-industry innovation.
स्मार्ट बॉल–वाल्व तकनीक से आप रिजनरेशन मोटर को प्रेशर पंप की तरह भी इस्तेमाल कर सकते हैं, या फिर अपने प्रेशर पंप को रिजनरेशन मोटर की तरह।13. World-Class Water Treatment Display Panel
A multilingual panel that provides real-time insights — adapter status, cleaning schedules, low salt alerts, and direct salt ordering options via integrated helpline.
दुनिया के सबसे स्मार्ट पैनल में आपको लाइव जानकारी मिलती है — जैसे मशीन की स्थिति, सफाई की समय-सारणी, लो साल्ट अलर्ट और सीधे नमक ऑर्डर करने का विकल्प।
Product : Fully Automatic Hybrid - Carbon and Sand Filter With Water Softener [Hybrid I-75] 4000 LPH
Attribute
Value
Vessel
Epoxy Coated Twin 13" X 54" FRP Vessels
Water Treatment Media (T1)
75 Kg - Coarse Sand + 1300 IV Carbon Mix Bed Media
Water Treatment Media (T2)
75 Litres Purity Hub High Cross-Linked Food Grade Resin
Multiport Valve (MPV)
Fully Programmable & Automatic Twin Multiport Valves with 4000 LPH Max. (25NB) Water Flow Rate (1 Inch)
Regeneration / Backwashing Motor
0.5 HP Regeneration & Backwashing Motor / Smart Ball-Valve Regeneration & Backwashing
Smart Info Panel
Yes (Refer to Product Images)
6 Way Bypass Valve
Yes (Refer to Product Images)
Brine Tank
100 Litres Brine Tank with Brine Assembly & Brine Level Controller [Round / Square]
Industrial Tablet Salt (NaCl) 99.5% Pure
50 Kg
Top & Bottom Strainer Set
Yes (20 MM)
Purity Hub's Patented Low Salt Indication Alarm
Yes
Smart Regeneration IC
Yes
System Safety Equipment 1
Vacuum Breaker for Vessels Safety
System Safety Equipment 2
MPV, Adopter & Motor Covers
System Safety Equipment 3
LP Switch for Multiport Valve & Regeneration Safety
